Features:

• Class D 2 ohms Stable 4-Channel-Channel Amplifier
• RMS Power Rating:
• 4 ohms: 80 watts x 4 channel
• 2 ohms: 125 watts x 4 channel
• Bridged, 4 ohms: 250 watts x 2 channel
• Total power output: 500 watts
• N-Channel MOSFET Transistors from Sanken® of Japan
• LED Power/Protect Light
• Full signal path low noise/distortion circuitry topology
• Output stage bias individually sequenced
• 3-way protection circuitry (thermal, overload, and speaker short protection)
• Total Harmonic Distortion (THD): 1%
• Signal to Noise Ratio: 90 dB
• Variable high-pass filter: 50 - 250 Hz
• Variable low-pass filter: 50 - 250 Hz
• Variable Bass Boost: 0 - 18 dB
• Fuse Rating: 50A
• 4 AWG gauge power and ground wiring is recommended for installation.
• Dimensions: 3.25" W x 12.25" L x 8" H

Specifications:

Power Specifications - Full Range Channels:

• RMS Power @ 4 ohms: 80 watts x 4 channel
• RMS Power @ 2 ohms: 125 watts x 4 channel
• Bridged RMS Power: 250 watts x 2 channel

Amplifier Specifications:

• Series: Power Class Series
• Marine Certified: No
• Amplifier Class: D
• Number of Channels: 4-Channel
• Total RMS Power Output: 500 watts
• Maximum Input Gauge Size: 4 AWG
• Minimum Impedance Unbridged: 2 ohms
• Minimum Impedance Bridged: 4 ohms
• Frequency Response: 20 - 36000 Hz
• THD at Rated RMS Power: 1%
• Speaker Level Inputs: Yes
• Preamp Outputs: 2 pairs
• Built-in Crossover: Low-Pass (LP), High-Pass (HP)
• High-Pass Crossover Frequency: 50 - 250 Hz
• Low-Pass Crossover Frequency: 50 - 250 Hz
• Signal-to-Noise Ratio: 90 dB
• Bass Boost: 0 - 18 dB
• Remote bass/level controller: Yes
• Fan Cooled: No
• Fuse Rating: 50A x 1
• Total Fuse Rating: 50A
• Strappable: No
• CEA-2031 Compliant: No
• Amp Bluetooth Connectivity: No
• Hi-Res Certified: No
• Low-Level Input Sensitivity: 200mV - 6 volts
